We dry your grains better !

|
| Place of Origin: | China |
| Brand Name: | Sunmero |
| Certification: | ISO9001 ISO14001 CE |
| Model Number: | 5HXH-32C |
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | $16000-50000/SET |
| Packaging Details: | Cotton Box, Wood Box |
| Delivery Time: | 15-30days |
| Payment Terms: | L/C, T/T, , Western Union, MoneyGram |
| Supply Ability: | 50Sets/Month |
| Dimension: | 2442*3714*13026mm | Capacity Per Batch: | 30Tons |
|---|---|---|---|
| Color: | Gray | ||
| High Light: | ISO9001 Paddy Grain Dryer 30Tons,30Tons Low Temperature Circulating Paddy Grain Dryer,30Tons ISO9001 Paddy Dryer Machine |
||
Production Describtion
High quailty grain after drying.Low drying cost. Large capacity, high efficiency and the cheapest drying.Long services life. Easy operating and maintenance.Multiple safety protection devices.
Feature:
Technical Parameters
| Model | 5HXH-20C | 5HXH-22C | 5HXH-30C |
| Type | Batch type circulation | ||
| Volume(t) | 20.0 | 22.0 | 30.0 |
| Overall dimension (L×W×H)(mm) |
2378×2375×12504 | 2378×2375×1 | 9630×4335×13026 |
| Hot air source | Hot blast stove (coal, husk, straw, biomass), Boiler(steam) | ||
| Blower motor power (kw) | 8.47 | 8.97 | 14.32 |
| The total power of Motor(kw) / Voltage(v) | 23.25/380 | 26.75/380 | 30.25/380 |
| Time of charging(min) | 45~56 | 55~65 | 65~76 |
| Time of discharging(min) | 43~54 | 52~62 | 62~73 |
| Moisture reduction rate per hour | 0.5~1.2% | ||
| Automatic control and safety device | Automatic moisture meter, automatic stop, temperature control device, fault alarm device, full grain alarm device, electrical overload protection device, leakage protection device | ||
